   4roll 3000×15 mm plate roll hydraulic MG

4 ROLL DUAL PRE-PINCH ROLLING MACHINE
-Width of plate 3000 mm
-Thickness of plate rolling 15 mm
-Thickness of plate pre-bend 12 mm
minimum bending diameter ID 350 mm
Rolls dimensions:
-Surface length mm. 3100
-Top roll mm. 290
-pinch roll mm. 270
-Power electric 10 Hp
Technical data:
-rolls hardened surface high resistance
-variable rolling speed
-Powered driven hydraulic rolls rotation
-conical bending attachment roller type
-calibration system re-rolling welded shells
-deflection pinch pressure adjustable upon the thickness
-overload protect complete safe operation of the machine.
-control console on wheels with electric joysticks commands
-position readout digital display for rolling memorize and repeat

Plate Roll  3000x40mm – model 4HCI3-35/30 -year 90 Faccin

PLATE BENDING ROLL LINEAR GUIDEWAYS DOUBLE PINCH PRE-BENDING

Bending capacity
-Plate width 3000 mm
-Rolling plate thickness 40 mm
-Prebend thickness 35 mm

Rolls dimensions: -Useful length 3050 mm
-central rolls upper/lower 470 mm
-side rolls left/right 420 mm

• Hardening of the 4 rolls high strength surface
• 3 rolls driven powered with gear unit with hydraulic motor
• Conical bending attachment side rolls tiltable to form cones, contrast pad roller type.
• Opening front hydraulic drop-end to unload the closed shell.
• Variable speed working roll bending rotation hydraulic speed fast/slow.
• Console electric on wheels with centralized commands joysticks and 3 digital readout.
• Digital readouts of the rolls position bending and pre-bending repeatability.
• Hydraulic tank capacity oil 350 liters – power electric 37 Kw voltage 380 /50
• Dimension 7700 x2410 x H 2470 mm – weight 43000kgs
